BFY-SZ Lift-down Type Slitter Scorer
Features:
◎ Slitting Part: adopt high quality tungsten steel blade, sharp and long work-life, slice more tidy, non-pressing and non-burr.
◎ Scoring Part: adopt 5 points scoring, scoring distance in-phase adjust, blazonry and easy to bend the carton sheet.
◎ Grinding Part: adopt automatic and manual two kinds pneumatic grinding type, it could be grinding when working, improve work efficiency.
◎ Electric control lift-down and correct error, easy to operate, suit for different requirements.
◎ Adopt China famous brand or imported electric element, dependable performance.
◎ Adopt synchronous belt drive, low noisy and work steady.
◎ It could be adopts double machine type, easy and fast change cutting order.
◎ Max running speed for production line:150m/min
Technical parameters:
Model | 2000 | 2300 | 2600 | |
Machine dimension(mm) | 3200*1200*2200 | 3500*1200*2200 | 3700*1200*2200 | |
Power | 8.5kw | 8.5kw | 8.5kw | |
Max slitting | Inverse blade | 1800mm | 2100mm | 2400mm |
Positive blade | 1800mm | 2100mm | 2400mm | |
Min slitting | Inverse blade | 140mm | 140mm | 140mm |
Positive blade | 140mm | 140mm | 140mm | |
Min scoring | Positive scoring | 30mm | 30mm | 30mm |
Inverse scoring | 80mm | 80mm | 80mm | |
Scoring height | 0-10mm | 0-10mm | 0-10mm | |
Blade(mm) | φ200*122*1.2 | φ200*122*1.2 | φ200*122*1.2 | |
Blade & Scoring | Three blade Four scoring/ Four blade |
