BFY thin blade slitter scorer machine(bottom can move type)
BFY thin blade slitter scorer machine(bottom can move type)

BFY thin blade slitter scorer machine(bottom can move type)

PRODUCT DESCRIPTION
Thin knife cutting part adopt newly type thin blade high-speed cutting machine,cardboard incision level off is smooth without crashing collapsing.
PRODUCT DETAILS

Thin knife cutting part adopt newly type thin blade high-speed cutting machine,cardboard incision level off is smooth without crashing collapsing; Pneumatic sharpening; this part to achieve production process to be automatic and manual sharpening, sharpening time and clearance can be set to ensure the blade, time blade sharp.

The machine is equipped with electric axial displacement device, effective cooperation of paper offset;

Manually adjust the cardboard specifications, simple and practical;

Transmission of the synchronous belt, high accuracy.


Technical parameters:

Machine dimension (mm)

3200×1100×2200

3500×1100×2200

3800×1100×2200

Power (KW)

5.5/7.6

5.5/7.6

5.5/7.6

Max slitting width (mm)

1800

2100

2300

Min slitting width (mm)

140

Min scoring width (mm)

80

Scoring height (mm)

0-12

Blade (mm)

φ200×122×1.2

Blade & Scoring Composed Type

Three blade Four scoring/ Four blade Six Scoring
/ Five Blades Eight scoring
